1. Quayside container crane introduction
▪ This product is designed in according with code for design of crane and international codes such as FEM,DIN,IEC and AWS.
▪ Electric control system, steel structure, machine room, main elevating mechanism, working mechanism of the traveling crab, working mechanism of the crane carriage, elevating mechanism of jib, assembly of traveling crab, hoisting tools, tilting mechanism, protection mechanism for suspended capsule as well as other necessary safety and auxiliary devices.
▪ Advanced technology of AC frequency-variable speed adjustment is adopted in the following parts: main elevating mechanism, working mechanism of jib.
▪ Equipped with single-and double-box hydraulic hoisting tools as well as mechanical or electronic anti-swing device. The product may be a towed one, a self-propelled one or with load-carrying traveling crab, available specifications of the products mainly include 30t, 35t, 40t, 45t, 50t, 61t and 65t.
Key words: Quayside container crane, container crane, quayside crane
2. Quayside container crane feature
▪ Reasonable structure and favorable performance.
▪ Smooth starting and stopping.
▪ Safe and reliable traveling, long life.
▪ Low noise, commodious cabin with good view.
▪ Easy installation and convenient maintenance.
▪ Excellent exchange ability for parts and components
3. Quayside container crane specification
▪ Load capacity: 30T-80T
▪ Lifting height: 10-22m
▪ Span:20-35m
▪ Lifting speed: 30m/min(60m/min)
▪ Trolley Traveling speed: 150m/min
▪ Wheel pressure: 400KN
Shore side container crane Performance parameters
|
Load capacity |
Under the spreader |
t |
30 |
35 |
40.5 |
50 |
61 |
65 |
|---|---|---|---|---|---|---|---|---|
|
Under hook |
35 |
38 |
50 |
60 |
55 |
75 |
||
|
Lifting height |
Rail （H1） |
m |
25 |
27.5 |
30 |
38 |
40 |
43 |
|
Under rail（H2） |
12 |
15 |
15 |
14 |
18 |
20 |
||
|
reach distance （L1） |
<38 |
38~42 |
38 |
55 |
56-63 |
56-66 |
||
|
Back reach （L2） |
7.5 |
10 |
10 |
18 |
20 |
20 |
||
|
track gauge （LK） |
10.5~18 |
22~26 |
16~35 |
16~35 |
16~35 |
16~35 |
||
|
Door frame width （B1） |
15.33 |
16 |
17 |
17 |
18.3 |
18.3 |
||
|
Contact frame beam height （H3） |
6.8~10 |
10~14 |
12~14 |
12~14 |
16.5 |
15.5 |
||
|
The two buffer distance （B） |
27 |
26.5 |
26.5 |
26.5 |
27 |
27 |
||
|
Lifting speed |
m/min |
50 |
35~50 |
50~70 |
50~70 |
75~90 |
75~90 |
|
|
120 |
70~120 |
120~150 |
180~210 |
150~180 |
150~180 |
|||
|
Speed |
150 |
120~180 |
150~180 |
180~210 |
180~210 |
180~210 |
||
|
45 |
45 |
45 |
45 |
45 |
45 |
|||
|
One-way pitch time m/min |
|
5 |
5 |
~6 |
~6 |
~6 |
~6 |
|
